Pop-up Series

Sturdy design, resistant to wind and snow loads

Versatile installation: balcony, wall, or ground

Pre-assembled for quick and easy setup

Adjustable tilt angle for optimized solar generation

Scalable system — easy to expand

Built-in Wi-Fi for remote monitoring via mobile APP

Category:

Solar Easy Kit

Specification

Model	IEK-P300	IEK-P400	IEK-P600	IEK-P800
PV Panel Input
Max Power	305W*1	410W*1	305W*2	410W*2
Max. Power Voltage Vmp	32.80V	31.45V	32.80V*2	31.45V*2
Max. Power Current Imp	9.30A	13.04A	9.30A*2	13.04A*2
Color	Black
Microinverter Output
Rated Output Power	300W	400W	800W	800W
Rated Output Current	1.3A	1.74A	2.6A	3.48A
Nominal Output Voltage/Range	220 / 230 / 240V
Nominal Frequency/Range	50 / 60Hz
CEC Peak Efficiency	96.70%
Monitoring
Communication Mode	WIFI
Cloud	Inver Cloud
APP	Inver Energy APP
Compliance
Module	CE / UL / CQC / IEC61215 / IEC61730
Microinverter	CE / VDE4105 / EN50549-1
General Data
Operating Temperature Range	-40°C ~ +65°C
Protection Rating	IP67
Cooling	Natural convection
Isolation Type	High Frequency Transformers (Galvanically Isolated)
Installation	Suitable for flat ground & balcony & wall (No installation required)
Warranty	12 years
Packing
Packages	1		2
Package Size	1480126070mm	1850125070mm	1480126070mm *2	1850125070mm *2
Container Loading	270Sets/40HQ		135Sets/40HQ
Components Included	Microinverter IS-030 1 Black brackets 1 305W Full black panel 1 5m end cable 1	Microinverter IS-040 1 Black brackets 1 410W Full black panel 1 5m end cable 1	Microinverter IS-060 1 Black Brackets 2 305W Full Black Panel 2 5m End Cable 1 DC Cable 2m *2	Microinverter IS-080 1 Black Brackets 2 410W Full Black Panel 2 5m End Cable 1 DC Cable 2m *2
